List of Connect Solutions
-
- Series name
- HF601series
- Features
-
Phillip lock type connector
• Excellent operability with good click feeling.
• Strong cable retention considering vibration and shock.
• Contact: Bottom contact (-02 and -03 type) and Vertical (-12 type).
• Lock: Phillip-type with rotating ZIF structure.
• Compatible cable: 0.3-mm thickness recommended. FFC/FPC-compatible types with and without ears.
• Supporting automatic mounting.
• Pb-free (RoHS compliant).
-
-
- Series name
- Y-LOCKseries
- Features
-
Connector with automatic locking function for automotive use
• One push to lock/unlock.
• Easy-to-mount structure.
• Function to prevent careless mistakes.
• Various numbers of contacts are available.
• Supporting automatic mounting.
• LV214 compliant.
-
- Series name
- HF507series
- Features
-
0.5-mm-pitch connector for high-speed transmission
• Side lock mechanism for superior operability.
• Allows straight/right-angle same-foot pattern mounting.
• Supporting high-speed (Gbps) transmission of signals, including LVDS, HDMI, and S-ATA signals.
• Compatible with a wide variety of cables.
Supported cables: YFLEX® (self-developed FPC cable), FFC, high-speed FFC, and discrete
• Differential impedance matching design.
• Prevents the slanted insertion and disconnection of cables.
• Supporting automatic mounting.
• RoHS compliant.
-
- Series name
- HF513series
- Features
-
High-speed transmission connector for automotive applications
• Industry’s smallest class, compact type (4.9 mm deep).
• High-speed transmission at 40 Gbps/ch class, supporting PCI Express 5.0, Thunderbolt 3, etc., combined with YFLEX® (YFBS Series).
• For high-temperature environments (125°C)
• Product design concept.
Induction design for ease of work and automatic insertion.
With automatic locking mechanism (unlocked with a single push).
Contact structure resistant to foreign materials (serrated contact).
Enables pattern wiring of the mounting board to the bottom of the connector.
-
- Series name
- FUS006/FUA006series
- Features
-
Micro SIM and nano SIM card
・Realization of small size by low-height design
・Card misinsertion prevention design
・RoHS compliant
・Product lineup for the application
Pull lever type
Tray type
-
- Series name
- FPS009series
- Features
-
SD memory card connector
・ Card misinsertion prevention design
・ Card pop-out reduction design
・ EMI countermeasure design
・ RoHS compliant
・ A variety of products are available
Normal mount / Reverse mount
Push lock type / One action lock type
Card detection switch
Half-insertion detection switch
Standoff type
Independent 2-point contact structure
-
- Series name
- PJS008series
- Features
-
micro SD card connector
・Card misinsertion prevention design
・EMI countermeasure design
・RoHS compliant
・A variety of products are available
Normal mount / Reverse mount
Push lock type / One action lock type
Independent 2-point contact structure for all contacts
2-point contact of original serration structure
